基于ARM的智能灯光控制系统（5）设备链表

设备自动动态更新

使用链表实现，方便数据实时动态增加与删除。

链表处理头文件 （link_pro.h）

函数	功能	使用
Create	创建链表头结点	stu_to_link( )
Delete	删除指定结点	dev_update( )
Insert	增加设备结点	stu_to_link( ) ， dev_update( )
dev_print	打印链表	init_sys( )
stu_to_link	结构体更新到链表	init_sys( ),ipcs_pro( )
link_to_stu	链表更新到结构体	dev_pro( )
find_id	通过id在链表中查询存在	dev_update( ) ，sw_pro( )
get_dev_id	通过id获取设备节点数据	sw_pro( )，area_sw_update（ ）

#ifndef __SL2000_LINK_H_
#define __SL2000_LINK_H_


struct sys_dev *Create(struct sys_dev main_dev);
struct sys_dev *Delete(struct sys_dev * head,int type);
struct sys_dev *Insert(struct sys_dev * head,struct sys_dev new_dev);
void dev_print(struct sys_dev *head);
struct sys_dev * stu_to_link(struct sys_dev *head);
void link_to_stu(struct sys_dev *head);
int find_id(char id,struct sys_dev *head,struct sys_dev *dev);
struct sys_dev *  get_dev_id(char id,struct sys_dev *head);
#endif

链表处理实现文件（link_pro.c）

#include "config.h"
#include "link_pro.h"

extern struct sys_all g_dev[1]; //系统配置结构体全局变量

struct sys_dev *Create(struct sys_dev main_dev)
{
    struct sys_dev *pNew=NULL;

    pNew=(struct sys_dev *)malloc(sizeof(struct sys_dev));
    if(NULL == pNew)
        printf("create malloc err...\n");

    pNew->connect_sta = main_dev.connect_sta;//主控设备设置连接
    strcpy(pNew->name,main_dev.name);
    pNew->join_sta = main_dev.join_sta;
    pNew->node.id = main_dev.node.id;
    pNew->node.type = main_dev.node.type;
    pNew->sw_sta = main_dev.sw_sta;
    pNew->bind_dev = main_dev.bind_dev;
    pNew->next = NULL;
    printf("plink create ok...\n");

    return pNew;
}


struct sys_dev *Insert(struct sys_dev * head,struct sys_dev new_dev)
{
    struct sys_dev *pNew = NULL;
    struct sys_dev *pFind = NULL;


    pNew=(struct sys_dev *)malloc(sizeof(struct sys_dev));
    if(NULL == pNew)
        printf("create malloc err...\n");

    pNew->connect_sta = new_dev.connect_sta;//主控设备设置连接
    strcpy(pNew->name,new_dev.name);
    pNew->join_sta = new_dev.join_sta;
    pNew->node.id = new_dev.node.id;
    pNew->node.type = new_dev.node.type;
    pNew->sw_sta = new_dev.sw_sta;
    pNew->bind_dev = new_dev.bind_dev;

    pNew->next = NULL;

    //新的节点，放在链表最后
    if(NULL==head)
        return pNew;
    else{
        pFind=head;
        while(pFind->next!=NULL)
        {
            pFind=pFind->next;
        }
        pFind->next = pNew;
    }
    printf("plink insert ok...\n");
    return head;
}

struct sys_dev *Delete(struct sys_dev * head,int type)
{
    struct sys_dev *pFind=NULL;
    struct sys_dev *pPrev=NULL;

    pFind=head;
    if(NULL==head){
        printf("设备列表为空!\n");
        return head;
    }
    while(pFind->node.type!=type && pFind->next!=NULL)
    {
        pPrev=pFind;
        pFind=pFind->next;
    }
    if(pFind->node.type==type)
    {
        if(head==pFind){
            head=pFind->next;
        }else{
            pPrev->next=pFind->next;
        }
        free(pFind);

        printf("%d 设备节点已删除.\n",type);
    }else{
        printf("设备列表中没有要删除的设备.\n");
    }
    return head;
}


void dev_print(struct sys_dev *head)
{
    struct sys_dev * p;
    p=head;

    if(NULL==head){
        printf("列表为空!\n");
    }else{
        printf("%d 个设备已连接。\n",g_dev->count_dev);
        while(p!=NULL){
            printf("类型:%d 名称:%s\n",p->node.type,p->name);
            p=p->next;
        }
    }
}

struct sys_dev * stu_to_link(struct sys_dev *head)
{
    int i;
    //通过配置文件，生成动态设备列表
    for(i=0;i<g_dev->count_dev;i++){
        if(i==0)
            head = Create(g_dev->sys_dev[i]);
        else
            head = Insert(head,g_dev->sys_dev[i]);
    }
    return head;
}

void link_to_stu(struct sys_dev *head)
{
    struct sys_dev * p;
    int i=0;
    int max = g_dev->count_dev;
    p=head;

    if(NULL==head){
        printf("列表为空!\n");
    }else{
        while(p!=NULL){
            g_dev->sys_dev[i].connect_sta = p->connect_sta;
            strcpy(g_dev->sys_dev[i].name,p->name);
            g_dev->sys_dev[i].join_sta = p->join_sta;
            g_dev->sys_dev[i].node.id = p->node.id;
            g_dev->sys_dev[i].node.type = p->node.type;
            g_dev->sys_dev[i].sw_sta = p->sw_sta;
            g_dev->sys_dev[i].bind_dev = p->bind_dev;
           p=p->next;
            if(i<=max)
                i++;
        }
    }
}

int find_id(char id,struct sys_dev *head,struct sys_dev *dev)//
{
    struct sys_dev * p;
    p=head;

    if(NULL==p){
        printf("列表为空!\n");
         return 0;
    }else{
        while(p!=NULL){
            if(p->node.type==id){
                if(dev!=NULL)
                    memcpy(dev,p,sizeof(struct sys_dev));
                return 1;
            }
           p=p->next;
        }
    }

    return 0;
}

struct sys_dev *  get_dev_id(char id,struct sys_dev *head)//
{
    struct sys_dev * p = NULL;
    p=head;

    if(NULL==p){
        printf("列表为空!\n");
         return NULL;
    }else{
        while(p!=NULL){
            if(p->node.type==id){
                return p;
            }
           p=p->next;
        }
    }

    return NULL;
}
